Specifications
| Max. Capacity of stirring | 3L |
| Stirring speed | 200~1500rpm |
| Temperature range | RT+~280℃ |
| Stir size | 50mm |
| Pan size | Φ135mm |
| Dimensions | 150*260*80mm |
| Machine Weight | 1.8kg |
| Panel Material | Pottery and porcelain coatings |
| Motor type | DC brushless motor |
| input power | 5W |
| output power | 3W |
| Heating power | 515W |
| Power Supply | 100~120/200~240V |
| Rated frequency | 50/60Hz |
| station number | 1 station |
| display mode | LED |
| RPM display resolution | - |
| Heating power | 500w |
| Temperature control Accuracy | ±1（＜100℃）±1%（＞100℃） |
| Safety protection temperature | 320℃ |
| Temperature display resolution | ±1℃ |
| Temperature transducer | PT1000 |
| External temperature transducer temperature control Accuracy | ±0.5 |
| Waste heat warning function | 50℃ |
| Data Interface | N/A |
| Protection level | IP21 |
| Allowable environment temperature | 5~40℃ |
| Allowable Relative Humidity | 80% |
Packing list
Host X1, external temperature probe X1, PT1000 temperature probe support assembly X1, quality assurance card X1, certificate of conformity X1, manual X1
After-sales instructions
Warranty days: 730 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/1870/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
