Specifications
| Max. Capacity of stirring | 400mL*10 |
| Stirring speed | 0~1100rpm |
| Heating power | 470W |
| Temperature range | RT+~120℃ |
| Stir size | 40mm |
| Pan size | 180*450mm |
| Dimensions | 182*622*65mm |
| Power Supply | 3.2kg |
| Panel Material | Stainless Steel Silicon Resin Film |
| Motor type | DC brushless motor |
| input power | 12W |
| output power | 4W |
| Heating power | 490W |
| Power Supply | 100~120/200~240V |
| Rated frequency | 50/60Hz |
| station number | 10 workstations |
| display mode | Scale |
| RPM display resolution | - |
| Heating power | 500w |
| Temperature control Accuracy | ±1（＜100℃）±1%（＞100℃） |
| Safety protection temperature | 140℃ |
| Temperature display | Scale |
| Temperature transducer | N/A |
| External temperature transducer temperature control Accuracy | - |
| Waste heat warning function | N/A |
| Data Interface | N/A |
| Protection level | IP42 |
| Allowable environment temperature | 5~40℃ |
| Allowable Relative Humidity | 80% |
| station number | 10 workstations |
Packing list
Host X1, quality assurance card X1, certificate of conformity X1, manual X1
After-sales instructions
Warranty days: 730 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/1875/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
