Specifications
| Measurement range | 5T |
| Force Precision | ≤0.3％ |
| Capacity segmentation | The whole process is not divided into gears, stepless speed regulation |
| Power system | AC servo motor + servo driver + worm gear reducer + ball screw |
| Control system | External Control mode |
| Walking space | 800Mm (including gripper) |
| Large deformation two-point extensometer | Resolution 1/100, Precision +/- 1mm |
| Safety Devices | Overload emergency shutdown device, up and down stroke limiting device, automatic breakpoint shutdown function |
| Speed control range | 0.01mm/min~ 500mm/min (Test speed can also be customized according to customer needs) |
| test width | 400mm |
| Power | About 2.3KW |
| Machine size | Approx. 910 × 650 × 2300 mm Length × Width × Height |
| Net Weight | 640kg |
Packing list
machine X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/19077/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
