Specifications
| Capacity selection | Choose one of 1000, 2000, 5000, 10000kg |
| Measurement and control software | The perfect test software under Windows 2000/XP platform |
| Force Precision | Better than +/- 1.0% |
| Force resolution | 1/100,000 |
| Measurement range | 0.5~100%F.S |
| Precision indication | Better than +/- 1.0% |
| Test speed range | 0.5~ 200mm/min, can be set arbitrarily |
| Test space | 120×120×120cm |
| Unit switch | Measurement units including SI units, users can also customize the required units |
| shutdown mode | Upper and lower limit safety settings, emergency stop button, program power and elongation settings, specimen damage sensing |
| Special features | Holding pressure test can be done |
| Standard configuration | 1 commercial computer, 1 color printer |
| optional configuration | 1 heightening seat for the testing machine |
| Machine size | 162*120*191cm |
| Weight | About 400kg |
| Power system | Digital AC servo motor |
| Power supply Voltage | 1PH, 220V, 50/60Hz, 15A or as specified |
Packing list
Host X1, commercial computer X1, color printer X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/19201/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
