Specifications
| Dimensions | 30 mm (diameter) x 142 mm (length) |
| Weight | About 88 grams |
| Support operating system | Windows, Mac, IOS and Android |
| Photo and Video Pixels | 1.30 million pixels, resolution: 1280x1024 (MJPG), 640x480, 320x240 |
| standard | Compatible with IEEE 802.11 b/g/n standard |
| Wireless transmission distance | More than 5 meters |
| Transmission power | 11n HT40 MCS7: +13 dBm 11b CCK: +18 dBm 11g OFDM: +15 dBm |
| data rate | 802.11n: up to 150Mbps; 802.11b: 1, 2, 5,5, 11Mbps;802.11g: 6, 9, 12, 18, 24, 36, 48, 54Mbps |
| Equipment maximum temperature | Working at full speed, below 60 ℃ (Celsius) |
| Frequency range | 2.400 ~ 2.4835GHz |
| Video frame rate | 10fps ~ 30fps |
| lithium battery | Continuous working time about 2 hours, fully charged time about 3 hours |
| Battery life | 500 cycles |
| Charging Power | DC5.0V/1A |
| Image Sensors | CMOS 1/4” |
| Exposure Control | automatic |
| gamma correction | automatic |
| Aperture | automatic |
| White equilibrate | automatic |
| Black reference | automatic |
| Flicker avoidance | automatic |
| defect identification | automatic |
| Color Saturation | automatic |
| Adjustable magnification | 450 times to 600 times |
| object distance range | 8~ 300 mm |
| Focusing range | 8~ 300 mm |
| lighting | 8 brightness adjustable warm white LEDs |
| lens | High definition Microscope |
| Photo and Video Pixels | 1.30 million pixels, resolution: 1280x1024, 640x480 |
| Computer interface | USB 2. 0 |
| Mini USB cable | 1.2 meters |
Packing list
Host X1, transparent lens cover X1, charger X1, data cable X1, plastic base X1, industrial professional accessories X1, calibration scale X1, instruction manual X1
After-sales instructions
Warranty days: 365 days
If the product quality is not artificially caused, the manufacturer provides 1 year free warranty service;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/19408/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
