Specifications
| lighting | Built-in 8 adjustable heating LEDs * 8 white |
| Dimensions | 36mm (diameter) 135mm (length) |
| Image Sensors | color |
| scan mode | progressive scan |
| MAX resolution | 2592 * 1944 (5038 * 848 pixels) |
| Sensors size | 1/2.5（5.70mm（H）*4.28mm（V）,对角7.13mm） |
| Pixel size | 2.2µm * 2.2µm |
| dynamic range | 70.1dB |
| analog-to-digital conversion | 12-bit/8-Bit R.G.B to PC |
| Signal to noise ratio | 38.1dB |
| Light spectrum Response | 380-650nm |
| Video Format and Frame Rate | 10 frames/s @2592 * 1944 15 frames/s @1920 * 1080 40 frames/s @1600 * 1200/1280 * 960/1280 * 720/1024 * 768/800 * 600/640 * 480 |
| pixel overlay | 1*1/2*2 |
| exposure capability | 3.9MS-320ms/automatic and manual |
| White equilibrate | Automatic and manual |
| software interface | DirectShow |
| recording mode | Photo and video (MJPG/AVI) |
| Optical inspection magnification | 0.28X-2X |
| object distance | 105mm |
| Focusing bracket lifting range | 230mm |
| Focusing handwheel adjustment range | 50mm |
| observation range | 20.4 * 15.3mm-2.86 * 2.15mm Continuously adjustable (L * D) |
| composite magnification | 19-135 continuous zoom, 76-540 continuous zoom (640-480) resolution preview decompression zoom zoom |
Packing list
Host X1, CD X1, Dust Film X1, Wipe Cloth X1, Standard Encasement X1
After-sales instructions
Warranty days: 365 days
If the product quality is not artificially caused, the manufacturer provides 1 year free warranty service;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/19418/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
