Pushen SHG 20-200 SHG comb WFT gauge 20-200μm

SHG 20-200

Comb wet Film Thickness Gauge

Range of 20~200μm, sub-scale 20μm, the number of teeth 10, shape unilateral type, material stainless steel, application standard GB/T 13452.2, ISO 2808.

SHG polar wet Film Thickness Gauge

It is very important to measure the wet film thickness of freshly applied coatings.

On the one hand, wet film thickness affects the coating quality of the product; on the other hand, excessively thick coatings can be expensive.

According to different coating methods, it is recommended to measure with a comb gauge.

Comb gauges are made of precision stainless steel, durable and reusable.

There are metric microns on each comb gauge as the unit of measurement.

Five ranges are available, up to 950 μm.

Instructions

When measuring, press a comb with a measuring range close to the estimated thickness of the paint film vertically into the wet film.

Remove the comb gauge from the wet film.

The wet film thickness shall be between the shortest tooth that is wetted by the wet film and the adjacent tooth that is not infiltrated.

Standards

GB/T 13452.2

ISO 2808

Packing list：Comb wet-film gauge × 1, instruction manual × 1

[Note]Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
