Specifications
| Measuring method | Platinum Ring |
| Measurement range of surface tension | 0~400mN/m |
| resolution | 0.1mN/m |
| standard error | +/- 0.1mN/m (secondary distillation water at 20 ℃) |
| Repeatability | ±0.1mN/m |
| Display mode | LCD |
| Operation mode | manual lift |
| Interface | RS232C |
| Power supply Voltage | AC220V±10V |
| Dimension | 300*290*400mm |
| Net Weight | 7kg |
| Data processing software | A set of Linear dispersion software is provided for free. By installing the program to the computer, the Linear dispersion diagram of the tension value, data and time can be displayed at the same time. Data can also be saved for customer inquiry. |
| Temperature control sample tank | Optional accessories (Thermostatic bath connection can control the temperature of the measured liquid) |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/19981/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
