Specifications
| Oscillation mode | reciprocating |
| Control mode | PID microcomputer |
| Display mode | LCD large screen backlit LCD screen |
| Convection mode | forced convection |
| Temperature range | RT+8~60 |
| Temperature Resolution | ±0.1℃ |
| Temperature Fluctuation | ±0.2℃ |
| Temperature Uniformity | ±1℃ |
| Oscillation Frequency | 30~250rpm |
| Cyclotron/Reciprocating Frequency Accuracy | ±1rpm |
| Oscillation Stroke | 0~50mm |
| Timer Range | 0~999h |
| Number of rocking boards | 1 piece |
| Power supply Voltage | AC220V 50/60Hz |
| Dimension | 1380*800*1010mm |
| Liner size | 1035*675*470mm |
| Pallet size | 950*635mm |
| Standard configuration | 2000ml*8 |
| Maximum configuration | 50ml*109 or 100ml*109 or 250ml*63 or 500ml*41 or 750ml*37 or 1000ml*22 or 2000ml*15 or 3000ml*12 or 5000ml*7 |
| Net Weight | 270kg |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/20083/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
