Specifications
| Oscillation mode | cyclotron |
| Control mode | PID microcomputer |
| Display mode | LCD large screen backlit LCD screen |
| Convection mode | forced convection |
| Temperature range | 4~60℃ |
| Temperature Resolution | ±0.1℃ |
| Temperature Fluctuation | ±0.2℃ |
| Temperature Uniformity | ±1℃ |
| Humidity range | 40~95% fluctuation: +/- 5% |
| Oscillation Frequency | 30~300rpm |
| Cyclotron/Reciprocating Frequency Accuracy | ±1rpm |
| Oscillation Stroke | Φ26mm |
| Timer Range | 0~999h |
| Number of rocking boards | 1 piece |
| Power supply Voltage | AC220V 50/60Hz |
| Dimension | 1350*700*1000mm |
| Liner size | 1010*590*470mm |
| Pallet size | 950*530mm |
| Standard configuration | 2000ml*6 |
| Maximum configuration | 50ml*71 or 100ml*71 or 250ml*45 or 500ml*37 or 750ml*29 or 1000ml*18 or 2000ml*15 or 3000ml*8 or 5000ml*7 |
| Net Weight | 210kg |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/20090/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
