Specifications
| Control mode | PID microcomputer |
| Display mode | LCD liquid crystal display |
| Drive mode | Single shaft drive |
| Temperature range | RT+6~60℃ |
| Temperature Accuracy | ±0.1℃ |
| Temperature Uniformity | ±1℃ |
| Oscillation mode | Swirling/spinning |
| Drive motor | DC brushless motor |
| Oscillation Frequency | 30~250rpm |
| Oscillation Stroke | φ 0-40mm stepless adjustable |
| Timer Range | 0~999h |
| Volume | 45L |
| Dimension | 620*600*520mm |
| Pallet size | 400*370mm |
| Number of rocking boards | 1 piece |
| Standard configuration | 250ml*8 |
| Maximum configuration | 50ml*23 or 100ml*23 or 250ml*13 or 500*9 or 750ml*6 or 1000ml*4 |
| Input Power | 700W |
| Power supply Voltage | AC220V 50/60Hz |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/20095/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
