Specifications
| Control mode | PID microcomputer |
| Display mode | LCD liquid crystal display |
| Drive mode | Single shaft drive |
| Temperature range | RT+6~60℃ |
| Temperature Accuracy | ±0.1℃ |
| Temperature Uniformity | ±1℃ |
| Oscillation mode | reciprocating |
| Drive motor | DC brushless motor |
| Oscillation Frequency | 25~240rpm |
| Oscillation Stroke | 40mm |
| Timer Range | 0~999h |
| Volume | 70L |
| Dimension | 750*750*510mm |
| Pallet size | 440*420mm |
| Number of rocking boards | 1 piece |
| Standard configuration | 250ml*10 |
| Maximum configuration | 50ml*32 or 100ml*32 or 250ml*16 or 500ml*12 or 750ml*8 or 1000ml*6 |
| Input Power | 700W |
| Power supply Voltage | AC220V 50/60Hz |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
