Specifications
| Mold sleeve specification | < unk > 25mm, < unk > 30mm, < unk > 40mm (choose one) |
| Cavity height | 108Mm, effective height 60mm |
| Heating power | Ф25mm 1kW; Ф30mm 1.2kW; Ф40mm 1.6kW |
| pressurized pressure | Factory setting 150bar (equivalent to 16Mpa, 160kgf, non-adjustable) |
| Heating setting range | 0~180 ℃ (factory setting 120 ℃) |
| holding time | Adjustable (factory setting: 40mm for 1 minute and 30 seconds, 25mm/30mm for 1 minute) |
| Chill down time | User-defined 1 minute~ 30 minutes (factory setting 2 minutes) |
| Total setting time | The < unk > 30 specification is about 7 minutes and 30 seconds, and the < unk > 40 specification is about 10 minutes. |
| Cooling mode | External water chilled down |
| Input power | Single Phase 220V, 50Hz, 16A |
| Dimensions | 520*480*520mm |
| Net Weight | 60Kg |
Packing list
Host X1, swirl/spin handle X1, upper module X1, oil pump breathing cover X1, water inlet pipe X1, water outlet pipe (< unk > 10mm) X1, water inlet filtrate net X1, clamp X1, inlaid powder (500g) X1, glassgraduates with scale X1, product manual X1, certificate X1
After-sales instructions
Warranty days: 365 days
If the product quality is not caused by human beings, the manufacturer will provide 1 year free warranty service (except for accessories/fragile and consumable products)
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/20226/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
