Specifications
| Mold sleeve specification | If you want 25mm, 30mm, 40mm, choose one of them. |
| Cavity height | 140Mm, effective height 85mm, can inlay 2 samples at the same time |
| Heating power | Ф25mm 1kW; Ф30mm 1.2kW; Ф40mm 1.6kW |
| pressurized pressure | 50~200Bar (factory setting 150bar, equivalent to 15Mpa, 150kgf) |
| Heating setting range | 50~180 ℃ (factory setting 120 ℃) |
| holding time | User-defined 30 seconds~ 7 minutes (factory settings 1 minute) |
| Heating time | User-defined 1 to 7 minutes (factory settings 4 minutes and 30 seconds) |
| Chill down time | User-defined 1 minute~ 30 minutes (factory setting 2 minutes) |
| Total setting time | It takes about 7 minutes and 30 seconds for 2 samples with a specification of < unk > 30, and about 9 minutes for 2 samples with a specification of < unk > 40. |
| Cooling mode | External water chilled down |
| Input power | Single Phase 220V, 50Hz, 10A |
| Dimensions | 530 * 510 * 480Mm upper cover opening height 85mm |
| Net Weight | 60Kg |
Packing list
Host X1, middle block X1, oil pump breathing cover X1, water inlet pipe X1, water outlet pipe (< unk > 10mm) X1, water inlet filtrate net X1, clamp X1, inlaid powder (500g) X1, glassgraduates with scale X1, inner hexagonal wrench X1, brush X1, product manual X1, certificate X1
After-sales instructions
Warranty days: 365 days
If the product quality is not caused by human beings, the manufacturer will provide 1 year free warranty service (except for accessories/fragile and consumable products)
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/20227/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
