Specifications
| grinding disc diameter | 230mm |
| Sandpaper diameter | 230mm |
| Rotation speed | Stepless speed regulation 50~1000r/min and four-speed speed regulation 250, 500, 750, 1000r/min, can be switched |
| disc steering | Clockwise and Counterclockwise, switchable |
| Mill motor | Servo motor, 220V, 750W |
| Grinding head motor | Servo motor, 220V, 400W |
| Rotation speed of grinding head | Stepless speed regulation 20~120r/min |
| Timed adjustable time | 0~99min |
| Sample clamping quantity | Four. |
| Specimen clamping specification | φ 25mm, φ 30mm, φ 40mm any specification (can be customized) |
| Pressurization method | Single point pneumatic pressure |
| pressurized pressure | 0~60N |
| Display and operation | 8 inch high definition LCD touch screen, grinding head automatic locking function, liner cleaning function |
| Input power | Single Phase 220V, 50Hz, 6A |
| Dimension | 420×660×630mm |
| Net Weight | 50kg |
Packing list
Host X1, automatic grinding head X1, grinding and throwing disc (230mm) X1, magnetic disc (230mm) X1, gasket (230mm) X4, adhesive-backed sandpaper (230mm) X6, adhesive-backed polishing cloth (230mm) X2, water inlet pipe X1, water outlet pipe (0019 32mm) X1, water inlet filtrate net X1, trachea (0019 6mm) X1, air Filter X1, inner hexagonal wrench (2mm, 3mm, 5mm) X3, manual X1, certificate X1
After-sales instructions
Warranty days: 365 days
If the product quality is not caused by human beings, the manufacturer will provide 1 year free warranty service (except for accessories/fragile and consumable products)
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/20238/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
