Specifications
| Disc diameter | Φ254mm |
| Sandpaper diameter | 250mm |
| Grinding head motor | DC brushless motor, 220V, 1.2kW |
| Grinding head motor | Stepper motor, 200W |
| Rotation speed | 20~120rpm |
| Timed adjustable time | 0~99min |
| Sample holding quantity | Six. |
| Specimen clamping specification | dig 25mm, dig 30mm, dig 40mm any specification (can be customized) |
| Pressurization method | Single point pneumatic pressure and center pneumatic pressure |
| central pressurized pressure | 0~160N |
| Display and operation | 7-Inch high definition LCD touch screen, grinding head automatic locking function, automatic water outlet function |
| Power | Single Phase 220V, 50Hz, 12A |
| Dimensions | 1200*800*760mm |
| Net Weight | 134kg |
| Single point pressurized pressure | 0~50N |
| Speed regulation mode | stepless speed regulation |
Packing list
Host X1, automatic grinding head X1, sample chuck X2, sample horizontal tray X1, grinding and throwing disc (0019 254mm) X2, magnetic disc (0019 250mm) X2, gasket (0019 250mm) X6, adhesive-backed sandpaper (0019 250mm) X6, adhesive-backed polishing cloth (0019 250mm) X2, inlet pipe X1, outlet pipe (0019 32mm) X2, water inlet filtrate network X1, trachea (0019 6mm) X1, grinding head connecting cable X2, air Filter X1, inner hexagon wrench (2mm, 3mm, 5mm, 6mm) X4, manual X1, certificate X1
After-sales instructions
Warranty days: 365 days
If the product quality is not caused by human beings, the manufacturer will provide 1 year free warranty service (except for accessories/fragile and consumable products)
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/20245/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
