Specifications
| Disc diameter | Φ300mm |
| Sandpaper diameter | 300mm |
| Grinding head motor | DC brushless motor, 220V, 1.2kW |
| Grinding head motor | Stepper motor, 200W |
| Rotation speed | 20~120rpm |
| Timed adjustable time | 0~99min |
| Sample holding quantity | Six. |
| Specimen clamping specification | dig 25mm, dig 30mm, dig 40mm any specification (can be customized) |
| Pressurization method | Single point pneumatic pressure and center pneumatic pressure |
| central pressurized pressure | 0~160N |
| Display and operation | 7-Inch high definition LCD touch screen, grinding head automatic locking function, automatic water outlet function |
| Power Supply | Single Phase 220V, 50Hz, 12A |
| Dimensions | 1200*800*760mm |
| Net Weight | 134kg |
| Single point pressurized pressure | 0~50N |
| Speed regulation mode | stepless speed regulation |
Packing list
Host X1, automatic grinding head X1, sample chuck X2, sample horizontal tray X1, grinding and throwing disc (φ 300mm) X2, magnetic disc (φ 300mm) X2, gasket (φ 300mm) X6, adhesive sandpaper (φ 300mm) X6, adhesive polishing cloth (φ 300mm) X2, water inlet pipe X1, water outlet pipe (φ 32mm) X2, water inlet filtrate net X1, trachea (φ 6mm) X1, grinding head connecting wire X2, air Filter X1, inner hexagonal wrench (2mm, 3mm, 5mm, 6mm) X4, manual X1, certificate of conformity X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/20246/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
