Specifications
| Cutting method | Manual, fixture Y feed |
| Cutting blade size | Φ250*2*Φ32mm |
| Maximum cutting section | 65*65mm |
| Rotation speed | 2800rpm |
| Motor Power | 1.5kw |
| Cutting fixture | Quick clamp, jaw height 60mm |
| Power | 380V, 50Hz, 6A, three-phase four-wire |
| Dimensions | 700*520*1110mm |
| Weight | 170kg |
| Water tank Capacity | 60L |
| Flow rate of pump | 25L/min |
| Water tank size | 565*360*600mm |
| Net Weight of tank | 27kg |
| X-axis travel | 45mm |
| Y-axis travel | 270mm |
| Platform size | 130 * 190Mm, 12mm T slot |
Packing list
Host X1, water tank X1, cutting blade (Should 250 × 2 × Should 32mm, Resin abrasive wheels) X2, stay wrench (36mm, 14 × 17mm, 24 × 27mm) X3, water inlet pipe (1/2 metal pipe) X1, water outlet pipe (Should 32mm) X1, manual X1, certificate X1,
After-sales instructions
Warranty days: 365 days
If the product quality is not caused by human beings, the manufacturer will provide 1 year free warranty service (except for accessories/fragile and consumable products)
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/20255/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
