Specifications
| Cutting method | Gravity manual |
| Cutting blade size | Φ300*2*Φ32mm |
| Maximum cutting section | 85*85mm |
| Rotation speed of spindle | 2800rpm |
| Motor Power | 3kW |
| Cutting fixture | Quick clamp, jaw height 60mm |
| Power Supply | 380V, 50Hz, 10A, three-phase four-wire |
| Dimension | 730*700*540mm |
| Weight | 180kg |
| Platform size | 204 * 240Mm, 12mm T slot |
| Water tank Capacity | 60L |
| Flow rate of pump | 25L/min |
| Water tank size | 750*730*1200mm |
| Net Weight of water tank | 27kg |
Packing list
Host X1, water tank X1, cutting blade (Should 300 × 2 × Should 32mm, Resin abrasive wheels) X2, stay wrench (14 × 17mm, 24 × 27mm) X2, water inlet pipe (1/2 metal hard pipe) X1, water inlet pipe (1/2 metal hose) X1, water outlet pipe (Should 48mm) X1, manual X1, certificate X1
After-sales instructions
Warranty days: 365 days
If the product quality is not caused by human beings, the manufacturer will provide 1 year free warranty service (except for accessories/fragile and consumable products)
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/20257/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
