Specifications
| Cutting method | Automatic, spindle Y feed |
| feed rate | 0.7-36mm/min (adjust step size 0.1mm/min) |
| Cutting blade size | Φ205*1.2*Φ32mm |
| Maximum cutting section | Φ60mm |
| Y-axis travel | 200mm |
| spindle span | 125mm |
| Rotation speed | 500~3000rpm |
| Motor Power | 1300W |
| Platform size | 320 * 225Mm, 12mm T slot |
| Cutting fixture | Quick clamp, jaw height 45mm |
| Display and control | 7-Inch touchscreen display and control |
| Power | Single phase 220V, 50Hz, 10A (380V optional) |
| Dimensions | 850*770*460mm |
| Net Weight | 140kg |
| Water tank Capacity | 36L |
| Flow rate of pump | 12L/min |
| Water tank size | 300*500*450mm |
| Net Weight of tank | 20kg |
Packing list
Host X1, water tank X1, cutting blade (3kg) X2, cutting fluid (3kg) X1, stay wrench (14 × 17mm, 17 × 19mm) X2, inner hexagon wrench (3mm, 6mm) X2, water inlet pipe (1/2 metal pipe) X1, water outlet pipe (0019 32mm) X1, manual X1, certificate X1
After-sales instructions
Warranty days: 365 days
If the product quality is not caused by human beings, the manufacturer will provide 1 year free warranty service (except for accessories/fragile and consumable products)
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/20261/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
