Specifications
| Cutting method | Manual/automatic, platform Y feed |
| cutting mode | Continuous cutting, pulse cutting |
| feed rate | Manual control/automatic adjustable 1~ 240mm/min |
| Cutting blade size | Φ300*2*Φ32mm |
| Maximum cutting section | Φ90mm |
| Y-axis travel | 260mm |
| X-axis travel | 40mm |
| Z-axis travel | 50Mm, manual adjustment |
| Rotation speed | 500~3000rpm |
| Motor Power | 4kW |
| Platform size | 435 * 300Mm, 12mm T slot |
| Cutting fixture | Quick clamp, jaw height 60mm |
| Display and control | 7-Inch touch screen display and control, membrane button control |
| Power | 380V, 50Hz, 12A, three-phase five-wire |
| Dimensions | 910*935*1350mm |
| Host weight | 430kg |
| Water tank capacity | 80L |
| Flow rate of pump | 50L/min |
| Water tank size | 610*550*680mm |
| Net weight of tank | 85kg |
Packing list
Host X1, water tank X1, cutting blade (Should 300 × 2 × Should 32mm, Resin abrasive wheels) X2, cutting fluid (3kg) X1, rigid hand (14 × 17mm, 24 × 27mm) X2, inlet pipe (1/2 metal pipe) X1, outlet pipe (Should 48mm) X1, exhaust pipe X1, wind X1, manual X1, certificate X1
After-sales instructions
Warranty days: 365 days
If the product quality is not caused by human beings, the manufacturer will provide 1 year free warranty service (except for accessories/fragile and consumable products)
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/20262/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
