Specifications
| Control mode | Manual/automatic, three-axis linkage, 10-inch industrial touch screen control, can also be switched to operation handle control |
| Performance characteristics | Schneider Electric, Mitsubishi Software, automatic fog removal system, alarm system, dual LED lighting, red cursor positioning |
| feed rate | 1~200mm/min（建议5~12mm/min） |
| Cutting blade size | Φ380*2.8*Φ32mm |
| Platform size | 450*350mm |
| Y-axis travel | 250mm |
| X-axis travel | 100mm |
| Z-axis travel | 200mm |
| Maximum cutting section | 120*120mm |
| Clamp opening | 120mm |
| Spindle motor | ABB variable frequency motor, 5.5kW |
| Rotation speed | 500~2800rpm |
| Feed motor | Servo motor |
| Power | 380V, 50Hz, 30A three-phase five-wire |
| Dimensions | 1450*1000*1850mm |
| Weight | About 1800kg |
| Water tank capacity | 120L |
| Flow rate of pump | 100L/min |
| Water tank size | 700*630*800mm |
| Tank weight | 90kg |
Packing list
Host X1, water tank X1, cutting blade X2, cutting fluid (3kg) X1, stay wrench X1, inner hexagon wrench (6mm, 8mm) X2, casing wrench (24mm) X1, water inlet pipe X1, water outlet pipe X1, manual X1, certificate X1
After-sales instructions
Warranty days: 365 days
If the product quality is not caused by human beings, the manufacturer will provide 1 year free warranty service (except for accessories/fragile and consumable products)
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/20266/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
