Specifications
| Cutting method | Manual/automatic, spindle feed or platform feed |
| Feed speed | Manual control/automatic adjustable 1-36mm/min (adjustment step size is 0.1mm/min, maximum speed is zero load state) |
| Cutting blade size | Φ180×1×Φ22mm |
| Maximum cutting diameter | Φ 30mm |
| maximum travel | Spindle travel 140mm, platform travel 230mm |
| Rotation speed of spindle | 500-3000r/min |
| Motor Power | DC brushless motor, 1.2kW |
| Platform size | 245 × 415Mm, 8mm T slot |
| Cutting fixture | Quick clamp, jaw height 45mm; vertical clamp, opening 60mm |
| Display and control | 7-Inch touchscreen display and control |
| Power input | Single Phase 220V, 50Hz, 8A |
| Dimension | 620×740×380mm |
| Net Weight | 80kg |
| Water tank Capacity | 36L |
| Flow rate of pump | 12L/min |
| Water tank size | 300×500×450mm |
| Net Weight of water tank | 20kg |
Packing list
Host X1, cutting blade (0019 180 × 0.8 × 0019 22mm, diamond abrasive wheels) X1, cutting fluid (3kg) X1, stay wrench (22mm, 14 × 17mm) X2, inner hexagonal wrench X1, custom wrench X1, vertical fixture X2, power cord X1, manual X1, certificate X1
After-sales instructions
Warranty days: 365 days
If the product quality is not caused by human beings, the manufacturer will provide 1 year free warranty service (except for accessories/fragile and consumable products)
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/20270/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
