Specifications
| working language | Full Chinese interface and operation |
| Error of indication | ±HRC0.2 |
| Display | 12864 spot vibration LCD with backlight |
| Hardness system | HL/HRC/HRB/HB/HV/HS/σb |
| Measurement range | HL170~960、HRC17~69、HRB13~101.7、HB20~655、HV80~940、HS32~99.5、σb(rm)255~2180N、mm2 |
| Impact device | D probe |
| communication distance | Open 10m |
| Impact direction | full angle |
| Measurement material | 10 Common Metal Materials |
| Data storage | 300 data, can be stored and read again |
| statistics | automatic calculation |
| Adjustment | Users can calibrate themselves |
| Communication interface | Data transfer through USB interface or Bluetooth connection to the computer |
| prompt | Low power prompt |
| Print function | Optional wireless micro printer |
| Alarm function | Upper and lower limit overrun alarm |
| Power Supply | 3.7V rechargeable lithium battery |
| Automatic shutdown | automatic |
| Power Supply | 2 1.5V AA alkaline batteries (host) 3.7V lithium battery rechargeable battery USB interface charging (wireless probe) |
| Operating temperature | –10 ~+40℃ |
| Dimensions | 124*67*30mm |
| Net Weight | 240g |
| meet the standard | Compliant with ASTM A956, DIN50156, GB/T17394-1998 standards |
Packing list
HTP1700 host X1, D-type wireless Bluetooth digital probe X1, small support ring X1, D test block X1, AA battery X1, small brush X1, operation manual X1, factory test report X1, warranty card X1, certificate X1, carrying case X1
After-sales instructions
Warranty days: 730 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/20356/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
