Specifications
| Error of indication | ±HL2 / ±HRC0.2 / ±HB2 / ±HV2 |
| Display | Digital LCD display with backlight |
| Hardness system | HL/HRC/HRB/HB/HV/HS/HRA/σb |
| Measurement range | HL100~960、HRC1~74.7、HRB1.2~140、HB28~1027、HV45~1230、HS4.0~112、HRA7~88.5、σb(rm)118~3315N、mm2 |
| Impact device | Type D (built-in) |
| Impact direction | 360 degree fully automatic |
| Measurement material | 10 Common Metal Materials |
| Data storage | 999 data, can be stored and read again |
| statistics | MAX Maximum, MIN Minimum, Automatic Average Calculation |
| Adjustment | Users can calibrate themselves |
| prompt | Low power prompt |
| Power Supply | One AA battery |
| Operating temperature | -20~+45℃ |
| Dimensions | 148*45*21mm |
| Net Weight | 105g |
| meet the standard | Compliant with ASTM A956, DIN 50156, GB/T 17394-1998 standards |
Packing list
Host X1, built-in D-probe X1, D test block X1, data management software X1, USB cable X1, small brush X1, No. 7 battery X1, test report X1, operation manual X1, carrying case X1
After-sales instructions
Warranty days: 730 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/20357/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
