Specifications
| Measurement principle | Eddy Current |
| Measurement range | 0~1000μm |
| margin of error | ±3% |
| Resolution | 0.1μm|1μm |
| Minimum radius of curvature | Convex 5mm; Concave 25mm |
| thinnest substrate | 0.4mm |
| probe | NF integrated probe |
| statistical function | Measurement Times, MAX Maximum, MIN Minimum, Average |
| icon function | without |
| Power Supply | 2 * AA alkaline battery |
| Calibrated Certificate | without |
| system language | Chinese |
| Display screen | LCD screen |
| supporting software | without |
| Machine Weight | 99g |
| Machine size | 102*62*27mm |
| Operating temperature | 0~50℃ |
| Minimum measurement surface | 10*10mm |
| Relative Humidity | 20~90%RH |
Packing list
instrument case x1, host x1, standard piece x4, aluminum base x1, battery x2, cleaning cloth x1, warranty card x1 attached to the manual, certificate x1.
After-sales instructions
Warranty days: 365 days
【Attention】
1. The manufacturer promises to provide a one-year warranty period for the product for customers in Nanbeichao Mall
2. During the warranty period, the freight sent back and forth by the customer shall be borne by the customer
3. The damage caused by improper use by customers and the damage caused by the logistics process are not covered by the free warranty.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/206/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
