Specifications
| Measurement principle | Magnetic Induction |
| Measurement range | 0~500μm |
| margin of error | ±(1~3% )H±1/H±2μm |
| Resolution | 0.1μm |
| Minimum measurement surface | Φ6mm |
| Minimum radius of curvature | Concave radius: 5mm; Convex radius: 1.5mm |
| Measurement mode | Lite mode, Monitoring mode, Statistics mode, MIN Minimum capture |
| Power Supply | Two AA batteries |
| system language | Built-in Chinese, English |
| Operating temperature | -10℃~+40℃ |
| Relative Humidity | ≤90%RH |
| Machine Weight | 220G (including battery) |
| Machine size | 150mm(L)*68mm(W)*33mm(H) |
| Temperature compensation | Equipped with TEC's new "phase-locked loop" technology |
| Measurement speed | According to different applications, customers can choose single measurement and continuous measurement Measurement speed |
| Display Accuracy | 0~100μm: 0.1μm; 100~999μm: 1μm; 1mm~9mm: 0.01mm |
Packing list
whole machine X1, F0.5 probe X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
