Specifications
| Measurement principle | Magnetic Induction |
| margin of error | ±3% |
| Resolution | 0.1μm|1μm |
| Minimum radius of curvature | Convex 5mm; Concave 25mm |
| thinnest substrate | 0.4mm |
| probe | F integrated probe |
| statistical function | Measurement Times, MAX Maximum, MIN Minimum, Average |
| icon function | without |
| Power Supply | 2 * AA alkaline battery |
| Calibrated Certificate | without |
| system language | Chinese |
| Display screen | LCD screen |
| supporting software | without |
| Machine Weight | 99g |
| Machine size | 102*62*27mm |
| Operating temperature | 0~50℃ |
| Minimum measurement surface | 10*10mm |
| Relative Humidity | 20~90%RH |
Packing list
instrument case x1, host x1, standard piece x4, iron base x1, battery x2, cleaning cloth x1, warranty card x1 attached to the manual, certificate x1.
