Specifications
| Acceleration Measurement range | Piezoelectric Vibration Sensors |
| Speed Measurement range | 0.01~ 199.9mm/s true RMS |
| Displacement Measurement range | 0.001~ 1.999mm peak-peak |
| Acceleration frequency range | 10Hz~10kHz |
| Speed frequency range | 10Hz~1kHz |
| Displacement frequency range | 10Hz~1KHz |
| Accuracy | ± (5% n + 2) words |
| Operating Temperature | 0~50°C |
| Operating Humidity | <90%RH |
| Power | 4 AA batteries |
| Dimensions | 160*68*32mm |
| Weight | 181G (without battery) |
Packing list
Host X1, magnetic suction seat X1, Piezoelectric Sensors X1, probe (cone) X1, probe (ball) X1, portable case X1, instruction manual X1
After-sales instructions
Warranty days: 730 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
