Specifications
| Sensors Type | Three Piezoelectric Vibration Sensors |
| Acceleration Measurement range | 0.1~400m/s² 峰值0.3~1312ft/s² 0.0~40g |
| Speed Measurement range | 0.01~ 400mm/s True RMS 0.004~ 16.0inch/s |
| Displacement Measurement range | 0.001~ 4.0mm Peak-Peak 0.04~ 160.0mil |
| Acceleration frequency range | 10Hz~10kHz |
| Speed frequency range | 10Hz~1kHz |
| Displacement frequency range | 10Hz~1KHz |
| Accuracy | ± (5% n + 2) words |
| Operating Temperature | 0~50°C |
| Power | 4 AA batteries |
| Dimensions | 140*73*35mm |
| Weight | 415G (without battery) |
| Operating Humidity | <90%RH |
Packing list
Host X1, magnetic suction seat X1, Piezoelectric Sensors X1, probe (cone) X1, probe (ball) X1, portable case X1, instruction manual X1
After-sales instructions
Warranty days: 730 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/20704/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
