Specifications
| monitor | Four-digit large LCD, forward and reverse dual display |
| Measurement range | ±100kgf/±980N/±220Lbf |
| error of indication | +/- 0.2% FS (range) +/- 1 digital peak |
| Power Supply | 2 AA batteries, or 6V DC Power Supply |
| Dimension | 211*80*36 mm |
| Weight | 390g |
| Load Graduation | 0.001kgf、0.1N、0.01Lbf |
| Precision | Level 0.2 |
| unit | Kgf、N、Lbf、gf |
| Measured value | Peak, instantaneous value |
| shutdown mode | 10 minutes automatic shutdown or manual shutdown |
| Backlight | Blue backlight |
| allowable load | 150% F.s (if it exceeds 110% F.s, there will be a beep alarm) |
| Operating temperature | 0~40℃ |
| Allowable Relative Humidity | < 80% |
| Operating Environment | No source and corrosion medium around |
Packing list
Electronic tension meter X1, tension hook X1, flat probe X1, conical probe X1, V-shaped groove probe X1, V-shaped wedge probe X1, extended connecting rod (double head screw and double head nut) X1, instruction manual X1, portable case X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/20748/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
