Specifications
| Coating method | Wire rod/drawdown blade |
| Coating size | 300*200*8mm |
| Spreader trip | 250mm |
| Coating speed | 1~150mm/s |
| Applicator Specification | Bar diameter 6~ 12.7mm, length greater than 220mm |
| Control mode | key control |
| Display | digital explicit |
| Total power consumption | 40W |
| Applicable standards | ASTM D823 |
| Host Power Supply | 110~240VAC/50~60Hz |
| Dimensions | 335*400*190mm |
| Machine Weight | 12.5 kg |
| speed Accuracy | <1％ |
| Precision of stroke length | <1mm（0.025mm/步） |
| Testing substrate maximum size | DIN A4 |
| Testing substrate thickness | 8Mm (including coating) |
| Maximum height of film applicator | 40mm |
| Drip pan Capacity | 30 ml |
| Display | 128 * 64 pixel graphic LCD, 70 mm * 40 mm, white lighting |
| language | English |
Packing list
Host X1, 24V adapter X1, paper holder X1, drip tray X1, Glass bed X1, rubber pad X1, weight X1, manual X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/20773/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
