Specifications
| Coating method | Wire rod/drawdown blade |
| Coating size | 300*200*8mm |
| Application width | 200mm |
| Spreader trip | 250mm |
| Coating speed | 1~150mm/s |
| Applicator Specification | Bar diameter 6~ 12.7mm, length greater than 220mm |
| Control mode | key control |
| Display | digital explicit |
| Total power consumption | 40W |
| Host Power Supply | 110~240VAC/50~60Hz |
| Dimensions | 335*400*190mm |
| Machine Weight | 12.5 kg |
| speed Accuracy | <1％ |
| Precision of stroke length | <1mm（0.025mm/步） |
| Testing substrate maximum size | DIN A4 |
| Testing substrate thickness | 8Mm (including coating) |
| Maximum height of film applicator | 40mm |
| Drip pan Capacity | 30 ml |
| Display | 128 * 64 pixel graphic LCD, 70 mm * 40 mm, white lighting |
| language | English |
| vacuum | -100 mbar |
| Vacuum aperture | Φ22mm |
| Number of holes in a vacuum bed | 117 |
| Vacuum connection | 6mm |
Packing list
Host X1, 24V adapter X1, paper rack X1, drip tray X1, weight X1, manual X1, vacuum bed X1, cushion (1 meter) X1
After-sales instructions
Warranty days: 365 days
