Specifications
| measurement principle | Magnetic Induction + eddy Current |
| Measurement Range | 0~1250μm |
| margin of error | ±1~3% |
| resolution | 0.1μm|1μm |
| Minimum radius of curvature | Convex 5mm; Concave 25mm |
| thinnest substrate | 0.4mm |
| probe | F and NF split probes |
| statistical function | Measurement Times, MAX Maximum, MIN Minimum, Average |
| icon function | without |
| Power Supply | Three (7) alkaline batteries |
| Calibrated Certificate | without |
| system language | Chinese, English |
| Display screen | 2.3-Inch large color screen with large font size display |
| supporting software | without |
| Weight | 100g |
| Dimensions | 130*70*24mm |
| operating temperature | 0~60℃ |
| Minimum measurement surface | Φ16mm |
| thinnest substrate | 0.4mm |
| Relative Humidity | 20~90%RH |
| Calibrated mode | Zero point calibrated, two point calibrated, multi point calibrated |
| shutdown mode | Manual/Automatic |
| Measurement method | Continuous measurement and single measurement |
Packing list
Encasement box x1, host with probe x1, calibration shim x4, iron matrix x1, aluminum matrix x1, certificate of conformity, manual x1
After-sales instructions
Warranty days: 365 days
【Attention】
1. The manufacturer promises to provide a one-year warranty period for the product for customers in Nanbeichao Mall
2. During the warranty period, the freight sent back and forth by the customer shall be borne by the customer
3. The damage caused by improper use by customers and the damage caused by the logistics process are not covered by the free warranty.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/211/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
