Specifications
| Measurement principle | Eddy Current |
| Measurement range | 0 ~ 1250µm |
| margin of error | ±3% |
| Resolution | 0.1mm | 1mm |
| Minimum radius of curvature | Convex 5mm; Concave 25mm |
| thinnest matrix | 0.3mm |
| probe | NF Split Probe |
| Statistical function | Average, MAX Maximum, MIN Minimum, Number of Tests |
| icon function | without |
| Power | 3 * AAA alkaline battery |
| Calibrated Certificate | without |
| Language | Chinese |
| Display screen | LCD |
| supporting software | without |
| Total Weight | 100g |
| Complete-built unit size | 130*70*24mm |
| Operating temperature | 0~50℃ |
| Minimum measurement surface | 10*8mm |
| Relative Humidity | 20~90%RH |
Packing list
Thickness gauge x1, calibrated diaphragm (50, 100, 250, 370 μm) x4, aluminum matrix x1, ABS instrument Encasement box x1, battery x1, manual x1, certificate x1, cleaning cloth x1
After-sales instructions
Warranty days: 365 days
【Attention】
1. The manufacturer promises to provide a one-year warranty period for the product for customers in Nanbeichao Mall
2. During the warranty period, the freight sent back and forth by the customer shall be borne by the customer
3. The damage caused by improper use by customers and the damage caused by the logistics process are not covered by the free warranty.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/212/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
