Specifications
| Lighting method | Observer angle: 2 °/10 ° Illumination: d/8 (Scattered Light source, 8 degree observation angle), SCI (including specular reflection component)/SCE (excluding specular reflection component) synchronous measurement function. |
| Sensors | Dual Path Array Sensors |
| Measurement range | 0~200% |
| Lighting source | Pulse xenon arc |
| Measurement time | 2s |
| Measurement caliber | Φ4mm/Φ6mm |
| Spectroscopic reflectance Repeatability | Standard deviation within 0.08% |
| Interface | USB, Bluetooth (customizable) |
| Available Light Sources | A,C,D50,D55,D65,D75,F1,F2,F3,F4,F5,F6,F7,F8,F9,F10,F11,F12,CWF,U30.DLF,NBF,TL83,TL84.U35 |
| Color difference formula | delta E * ab, delta E * CH, delta E * uv, delta E * cmc (2:1), delta E * cmc (1:1), delta E * 94, delta E * 00, delta Eab (Hunter), 555 shade classification |
| data storage | 20,000 pieces of test data |
| display mode | Light spectrum chart/data, sample chromatic value, color difference value, pass/fail result, Color bias, display measurement area, historical data color simulation, manual input standard sample, generate test report |
| Operating environment | 0-45 ℃, Relative Humidity 80% or less (at 35 ℃), no condensation |
| Storage environment | -25~ 55 ℃, Relative Humidity 80% or less (at 35 ℃), no water condensation |
| Dimensions | 181*73*112mm |
| Weight | About 550g (without battery) |
| Integrating sphere size | Φ40mm |
| Wavelength range | 360~740nm |
| wavelength interval | 10nm |
| Light spectrum Bandwidth | 5nm |
| Resolution | 0.01% |
| Measurement time | About 2s |
| Color Space | CIE-L * a * b, L * C * h, L * u * v, XYZ, Yxy, reflectance, Hunter-lab, Munsell MI, CMYK. RGB. HSB |
| Chroma indicator | WI, YI, TI, homochromatic index MI, colour fastness, discoloration fastness, force, coverage, tinting strength, strength, ISO luminance, 8 Glossiness, A density, T density, M density, E density |
| Inter-instrument Agreement | ΔE*ab<0.2 |
| Battery life | Charging, repeability, continuous measurement 10000 times, 7.4V/6000mAh |
| Display | Full color true color screen |
| Color scheme | can be matched |
| UV Light source | UV Light source |
| Repeatability of chromatic value | Delta E * ab 0.02, MAX Maximum 0.04 |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 1095 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/21267/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
