Specifications
| Cleanliness class | International ISO14644.1 standard CLASS 5 (US Federal 209E, level 100) |
| Average wind speed | 0.1~0.6m/s |
| Noise | ≤62dB(A) |
| Vibration Half-Amplitude | ≤ 3μm |
| Filter efficiency | Efficiency 99.99% |
| Illuminance | ≥300Lx |
| Dimensions | 1585*1460*735mm |
| Workspace size | 500*1300*680mm |
| Operating Environment | Environment temperature 10~30 ℃, Relative Humidity below 70%, no obvious vibration and dust around |
| Nominal power | 400W |
| Power | Single phase AC220V/50Hz |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 730 days
1. 2 years warranty service is provided by the original factory, and human damage is not covered by the warranty.
2. During the warranty period, all labor costs and accessories fees are exempted.
3. After the end of the warranty period, technical support and lifelong maintenance service will be provided by the original factory.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/21294/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
