Specifications
| Drawdown blade type | Integrated drawdown blade |
| Drawdown blade Accuracy | ±0.003mm |
| Drawdown blade thickness range | 0.001~ 10Mm adjustable |
| Coating speed | 5~ 200Mm/s (< 5mm/s can be customized) |
| Coating size | 300 * 400Mm (Miscellaneous size can be customized) |
| Drawdown blade material | 304 stainless steel |
| Drawdown blade length | 400mm |
| Host Power Supply | 220V 50Hz |
| Dimension | 626*410*520mm |
| Net Weight | 45KG |
| speed control | Infinitely variable speed |
| Coating table material | Glass plate |
| Control mode | Touch screen |
| Optional Accessories | Leakage tank, substrate fixture, trimming horizontal height support foot device, Glass plate, silicone pad and Weight (for applications with uneven thickness of Spreader substrate), application width control baffle |
| customizable function | Automatic lame plating device, UV curing device, automatic inking system, air knife drying, remote control, upper infrared heating, double extrusion Spreader |
Packing list
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/2135/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
