Specifications
| Instrument applicable | UV LED light source light intensity, energy, temperature measurement |
| Light spectrum range | 340Nm~ 420nm, instrument calibrated to 395nm light source |
| Power Measurement range | 0~20000mW/cm² |
| Power Resolution | 1mW/cm² |
| Energy Measurement range | 0~999999mJ/cm² |
| Energy measurement Accuracy | ± 10%, ± 5% typical |
| Temperature Measurement range | -55~125℃ |
| Sampling speed | 2048 times/second |
| Power data storage interval | 32 times/second |
| Temperature data storage interval | 16 times/second |
| recording period | 32 minutes |
| Instrument Power | 2 AAA alkalinity dry batteries |
| show | 240 * 160 dot matrix LCD |
| Instrument size | Diameter 120mm * Film thickness 13 mm |
| Instrument Weight | 327 g |
Packing list
V energy meter x1, USB data cable x1, AAA battery x2, anti-static gloves x2, small cross screw driver x1, manual x1, warranty card x1, lens paper x1, engineering box size 25 * 21 * 7 cm (L * W * H) x1
After-sales instructions
Warranty days: 365 days
If the product quality is caused by non-human factors, the manufacturer will provide 1 year free warranty service (except accessories and consumables);
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/2138/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
