Specifications
| Geometry | 60° |
| Measurement range | 0.0~199GU |
| Stability | 1GU |
| Error of indication | ±2GU |
| Division Value | 1GU |
| Zero Error | 0GU |
| Measuring Areas | 36*18mm |
| Measurement port shape | ellipse |
| Standards | ISO 2813、GB/T9754、ASTM D2457、ASTM D523、GB/T13891、GB/T7706、GB/T8807、JJG 696 |
| Dimensions | 148*46*86mm |
| Weight | 381g |
| Power | AC110~240(50/60HZ) |
| Charging time | 14~16h |
| Operating Time | >48h |
| Operating Temperature | 15~40℃ |
| Environment Operating Humidity | < 85%, no condensation |
| Storage temperature | -10~60℃ |
Packing list
1 host, 1 shockproof instrument box, 1 black Glass working board, 1 white Pottery and porcelain working board, 1 instrument power adapter, 1 user manual, 1 certificate, 1 warranty card, 1 lens cleaning cloth
After-sales instructions
Warranty days: 365 days
【After-sales service】
1. The instrument is guaranteed by the original factory for one year and repaired indefinitely.
2. The original factory provides free information technical support and consultation for gloss measurement.
3. The original factory provides indefinite instrument calibration service free of charge.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/21448/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
