Specifications
| Motor Power | 240W |
| Speed regulation range | 25000 rpm |
| Dimension | 130*250*145 mm |
| Power supply Voltage | 220 - 240 V |
| Weight | 3.13 kg |
| Process type | batch processing |
| Working principle | Shear/Impact |
| Motor Input Power | 300 W |
| Rotation speed deviation | 500±rpm |
| Maximum circumferential velocity | 73m/s |
| Maximum usage Volume | 50ml |
| Maximum Feed Hardness | 5Mohs |
| Maximum feed particle | 6mm |
| Impact/shear cutter head material | Stainless steel 1.4034 |
| Grinding chamber material | Stainless steel 1.4301 |
| Working time | 5 min |
| Working time | 10 min |
| Grinding room, chilled down with water | Yes |
| Grinding materials can be chilled down with dry ice in the grinding chamber | Yes |
| Environmental temperature | 5 - 40 ℃ |
| Allowable Relative Humidity | 80 % |
| Type of protection | IP 41 |
| Frequency | 50/60 Hz |
