Specifications
| Motor Power | 100W |
| Speed regulation range | 28000 rpm |
| Dimension | 85*240*85 mm |
| Power supply Voltage | 220 - 230 / 100 - 115 V |
| Weight | 1.5kg |
| Process type | batch processing |
| Working principle | Shear/Impact |
| Motor Input Power | 160W |
| Maximum circumferential velocity | 53m/s |
| Maximum usage Volume | 80ml |
| Maximum Feed Hardness | 6Mohs |
| Maximum feed particle | 10mm |
| Impact/shear cutter head material | Stainless steel 1.4034 |
| Grinding chamber material | Stainless steel 1.4301 |
| Working time | 1 min |
| Working time | 10 min |
| Grinding room, chilled down with water | Yes |
| Grinding materials can be chilled down with dry ice in the grinding chamber | Yes |
| Environmental temperature | 5 - 40 ℃ |
| Allowable Relative Humidity | 80 % |
| Type of protection | IP 43 |
| Frequency | 50/60 Hz |
