Specifications
| Rated Voltage | 230/100~115/100V |
| Rated Frequency | 50/60Hz |
| Input Power | 130W |
| output power | 84W |
| drive type | Brushless DC motor |
| Max Torque | 200N.cm |
| Control mode | stepless |
| Timer | 1~6000min |
| Rotation speed display | TFT |
| Impeller fixing method | Collet |
| Max Torque | 200N.cm/40N.cm |
| Rotary collet clamping range | Φ0.5~10mm |
| Processing Capacity | 100L |
| maximum viscosity | 100000mPa·s |
| Interface | USB |
| Environmental temperature | 5~40℃ |
| Allowable Relative Humidity | ≤80% |
| Dimensions of the whole machine | 91*395*231mm |
| Machine Weight | 5.9kg |
| intermittent operation | Yes |
| Maximum output power of mixing shaft | 84 W |
| Permissible continuous running time | 100% |
| Rotation speed control Accuracy | 1 ±rpm |
| Speed measurement deviation | N > 300rpm speed measurement deviation: 1 +/- % n < 300rpm speed measurement deviation: 3 +/- rpm |
| External temperature sensing interface | PT1000 |
| Temperature display function | Yes |
| Plug connection | Φ10 mm |
| Hollow shaft | 10.3 mm |
| bracket fixing | Extension arm chuck fixed |
| Extension arm diameter | 16 mm |
| Extend arm length | 220 mm |
| Torque display | Yes |
| Max Torque | 2Nm |
| Torque measurement | trend |
| Torque measurement deviation | 2.5 ±Ncm |
| Speed measurement deviation | 2.5 ±Ncm |
| Timer | Yes |
| Timer | TFT |
| Measurement Accuracy | 0.1K |
| Temperature measurement Accuracy | PT1000 Temperature deviation +/- 0.5 (DIN IEC 751 Class A) K |
| Limit deviation of temperature sensor | ≤ ± (0.15 + 0.002xITI) K |
| Shell material | Cast aluminum coating/thermal plasticity polymer |
| Maximum remote control distance (depending on the building) | 150 m |
| Protection level | IP40 |
