Specifications
| station number | 10 workstations |
| Max. Capacity of stirring | 400mL |
| Stirring speed | 0~1000rpm |
| Speed regulation mode | 10 RPM Steps |
| Temperature range | RT+~120℃ |
| Safety protection temperature | 50~150℃ |
| Heating power | 375W |
| Input Power | 410W |
| Mixer size | 25~30mm |
| Pan size | 180*495mm |
| Panel Material | aluminum alloy |
| Dimensions | 190*60*610mm |
| Power | 230/115/100V 50/60 Hz |
| Machine Weight | 7.5kg |
| Protection level | IP40 |
| Ambient Temperature | 5~40℃ |
| Allowable Relative Humidity | 80% |
| Mixing point spacing | 90mm |
| Temperature control mode | LED |
| Heating speed | 3 K/min |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/21502/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
