Specifications
| Rated Voltage | 100~240V |
| Rated Frequency | 50/60Hz |
| Input Power | 32W |
| output power | 22W |
| drive type | Brushless DC motor |
| Max Torque | 0.3Nm |
| Speed range | 30~500rpm |
| Speed regulation mode | Control knob |
| Timer | without |
| Rotation speed display | LED |
| Impeller fixing method | Collet |
| Max Torque | 30N.cm |
| Rotary collet clamping range | Φ0.5~8mm |
| Processing Capacity | 20L |
| maximum viscosity | 20000mPa·s |
| Lifting stroke | 160mm |
| Environmental temperature | 5~40℃ |
| Allowable Relative Humidity | ≤80% |
| Dimensions of the whole machine | 60*173*126mm |
| Machine Weight | 1.26kg |
| Shell material | Cast aluminum coating/thermal plasticity polymer |
