Specifications
| Measurement range | 0.7~400mm |
| Probe Frequency | 5MHz |
| Probe style | Split probe |
| Probe diameter | Φ10mm |
| Probe contact temperature | -10~50℃ |
| Measurement error | ±(0.5%H+0.05)mm |
| Display resolution | 0.01mm / 0.1mm |
| unit system | mm |
| Calibration method | Zero point calibrated, single point and two point calibrated Speed of sound |
| Measurement mode | Standard, scan, difference, average value, extreme value alarm, high temperature |
| Storage Capacity | 2000 groups |
| Speed of sound | 508~18699m/s |
| Display | 128 × 64 dot matrix LCD screen |
| Operating language | Chinese |
| Application Software | without |
| Power Supply | 2 * 5 battery |
| Operating Time | 280H (automatic mode)/100h (backlight on) |
| Host size | 136*72*20mm |
| Weight | 176G (including battery) |
| Application | Steel, cast iron, aluminum, copper, zinc, quartz, Glass, polyethylene (PE), PVC, gray cast iron, ductile cast iron and other materials of the measured object thickness measurement |
| scanning method | 2~20 times/sec. |
| Probe Frequency | 1~10MHz |
Packing list
host x1, standard probe (room temperature) x1, battery x2, manual x1, certificate x1, instrument case x1.
