Specifications
| Motor Input Power | 70W |
| Motor output power | 35W |
| Rotation speed display | LED |
| speed range | 60~2000rpm |
| maximum viscosity | 10000mPas |
| Maximum output power of mixing shaft | 26W |
| Permissible continuous running time | 100% |
| Maximum torque of stirring shaft | 150Ncm |
| Speed Range I (50Hz) | 60~500rpm |
| Speed Range II (50Hz) | 240~2000rpm |
| Speed Range I (60Hz) | 72~600rpm |
| Speed Range II (60Hz) | 288~2400rpm |
| Speed regulation mode | stepless |
| Rotation speed setting Accuracy | 1±rpm |
| Speed measurement deviation | 30 ±rpm |
| Rotary collet clamping range minimum diameter | 0.5 - 10 mm |
| Hollow shaft, inner diameter | 10.5 mm |
| Hollow shaft (can be inserted in stop state) | Yes |
| bracket fixing | Extension arm chuck fixed |
| Extension arm diameter | 13mm |
| Extend arm length | 160mm |
| Speed regulation mode | mechanical |
| Dimensions | 88 * 294 * 212 mm |
| Weight | 3.1kg |
| Environmental temperature | 5~40 ℃ |
| Allowable Relative Humidity | 80% |
| Power supply Voltage | 220~240/100~115V |
| Rated Frequency | 50/60Hz |
| Input Power | 72W |
| Timer | No. |
Packing list
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/21619/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
