Specifications
| Heating fabric | High density high aluminum porcelain material |
| Heating mode | Far infrared heating |
| Power | 220-240 volts AC, 50/60 Hz |
| Heating power | 3.8KW |
| Dimensions | 340*440*90mm |
| Heating dimension | 400*300mm |
| Temperature range | RT+~450℃ |
| Temperature control Accuracy | ±1℃ |
| Temperature measurement Accuracy | ±0.1℃ |
| Control system | Split PID intelligent program control, segmented control |
| time setting | 1min-999hR |
| output power | 5800W |
| Panel Material | High aluminum porcelain, microcrystalline ceramics, silicon carbide board, high purity graphite board |
| Pan size | 440*340mm |
Packing list
Host x1, thermostat x1, Sensors x1, power cable x1, instruction manual (certificate of conformity, warranty card) x1
After-sales instructions
Warranty days: 365 days
If the product quality is not caused by human causes, the manufacturer provides 1 year free warranty service
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/21680/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
