Specifications
| station number | 4 stations |
| Max. Capacity of stirring | 5L*4 |
| Maximum load Weight | 20L |
| Stirring speed | 100~2500rpm |
| Speed regulation mode | stepless speed regulation |
| Temperature range | RT+~450℃ |
| Temperature control Accuracy | ±0.5℃ |
| Heating power | 2400W |
| Mixer size | Φ12*35mm/Φ12*40mm/ Φ12*80mm |
| Pan size | 200*200*4 |
| Panel Material | German SCHOTT microcrystalline ceramics |
| Dimensions | 310*120*800mm |
| Power | 220V/110V |
| Machine Weight | 20kg |
| Ambient Temperature | 5~40℃ |
| Allowable Relative Humidity | <90% |
| Stirrer drive | ND servo motor |
| output power | 36W |
| temperature test | Built-in temperature control and external temperature control can be switched |
| Temperature control mode | LED digital display temperature free setting |
Packing list
host x1, stirrer x1, Sensors x2, power cable x1, bracket x1 set, instruction manual x1, warranty card x1.
After-sales instructions
Warranty days: 365 days
If the product quality is not caused by human causes, the manufacturer provides 1 year free warranty service
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/21685/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
