Specifications
| Measurement range | 0.7~400mm |
| Probe frequency | 5MHz |
| Probe style | Split probe |
| Probe diameter | F10mm |
| Probe contact temperature | -10~50℃ |
| Lower limit of pipe measurement | F15 * 1.0mm |
| Measurement error | ±(0.5%H+0.05)mm |
| Display resolution | 0.01mm / 0.1mm |
| Calibrated | Zero auto calibration |
| Measurement mode | Standard, MAX Maximum, MIN Minimum, Difference, Average, High Temperature |
| Storage Capacity | 2000 groups |
| Sound speed range | 509~18699m/s |
| Display | 128 × 64 dot matrix LCD |
| Operating language | Chinese |
| Application software | without |
| Power | 2 * 5 battery |
| Operating Time | 280H (auto mode)/100h (backlight on) |
| Host size | 136*72*20mm |
| Weight | 176G (including battery) |
| Application | Film thickness measurement |
| Cross coating Measurement Range | 3mm~20mm |
| Scanning speed | 2~20 times/sec. |
Packing list
host x1, standard probe x1, coupling agent x1, battery x2, manual x1, certificate x1, instrument case x1.
After-sales instructions
Warranty days: 365 days
【Attention】
1. The manufacturer promises to provide a one-year warranty period for the product for customers in Nanbeichao Mall
2. During the warranty period, the freight sent back and forth by the customer shall be borne by the customer
3. The damage caused by improper use by customers and the damage caused by the logistics process are not covered by the free warranty.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/217/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
